HomeFilaments3D-ABS+PC

3D-ABS+PC

ABS+PC is Specially designed for demanding industrial applications, it has excellent performance in impact resistance, heat resistance, and dimensional stability
The ABS mechanical printing consumables for 3D FISH are a breakthrough high-performance composite designed for demanding industrial applications, with outstanding performance in impact resistance, heat resistance and dimensional stability:
Technology and innovation
The optimized crystallization control technology greatly reduces the internal stress deformation of the printed parts, and has good anti-segregation performance. The innovative interlayer bonding enhancer effectively solves the problem of easy delamination in multi-layer printing.
Industrial-grade performance
Excellent impact resistance, is 3 times that of ordinary ABS, in addition to excellent heat resistance, especially excellent mechanical strength, tensile strength and bending modulus.
Stable reliability
Vehicle-grade quality control, each batch of materials are tested for complete mechanical and thermal properties, and special temperature stabilizers ensure consistent material performance during printing.
Ease of use and compatibility
Compatible with most industrial-grade FDM printers, including Stratasys, Ultimaker, etc., with a special formulation to ensure good adhesion on different construction board surfaces.
application scenarios
Suitable for electronics, high temperature resistant housing, terminal blocks, power sockets, outdoor equipment, weather-resistant housing, solar equipment components, auto parts, heat resistant interior parts and other parts.
Specifications parameters

Method of measurement

standard

characteristic

callipers

1.75±0.02mm

Wire diameter

callipers

≤ 0.02mm

roundness

electronic balance

1 ± 0.01KG/roll

weight

automatic measurer

1.75 ± 0.02mm

Diameter consistency

Surface

Method of measurement

standard

characteristic

Visual plus touch

Smooth, rounded, uniform thickness

surface

Visual plus touch

No bubbles, bulges, spots, etc

details

Visual additive color charts

The color is uniform with the color chart

pigment

visual

Neat and unblocked

rolling

Physical property

Method of measurement

standard

characteristic

density

1.15(g/cm³)

standard

distortion temperature

115℃

standard

melt index

7g/10min

standard

Vika softening temperature

122℃

standard

Mechanical behavior

Method of measurement

standard

characteristic

tensile strength

58MPa

standard

elongation at break

30%

standard

bending strength

85MPa

standard

flexural modulus

2400MPa

standard

Cantilever beam notch impact

45J/M

standard

×
