ABS-High Toughness

ABS High toughness Capable of withstanding repeated bending and severe impact without cracking, further improving impact toughness.
The ABS high-toughness 3D printing filament of 3D FISH adopts a breakthrough elastomer composite technology, so that the printed parts can withstand repeated bending and violent impact without cracking. While maintaining the excellent mechanical properties of ABS, the impact toughness is further improved:
Technology and innovation
The self-developed composite material formula enables the printing material to be dispersed directionally under impact, with excellent weather resistance. When used as protective equipment or shock-absorbing components, it can achieve true safety and lightweight.
Stable reliability
Ultra-high impact resistance, tested by robot joint application, no fatigue fracture after 100,000 times of action test, and reduce the brittleness of traditional ABS in low temperature environment, expanding the application scenarios of 3D printing.
Safety and environmental protection
The material has passed a number of safety certifications to prevent the migration of harmful substances, support the utilization of waste materials, and replace metal shock blocks with materials. The weight reduction of new energy vehicles effectively reduces the weight and improves the endurance.
Ease of use and compatibility
Compatible with mainstream models such as Creality Ender series and Prusa i3, and compatible with professional equipment such as Stratasys F series and Ultimaker S5 to meet high precision industrial needs.
application scenarios
Suitable for industrial shock damping components, replacing metal spring pads, weight reduced by 70%, sports protective equipment: customizable sports protective gear, UAV cushion landing gear, rehabilitation training assistive devices, space experiment equipment protective cover, robot joints, deformable grille components and other scenarios.

Specifications parameters

Method of measurement

standard

characteristic

callipers

1.75±0.02mm

Wire diameter

callipers

≤ 0.02mm

roundness

electronic balance

1 ± 0.01KG/roll

weight

automatic measurer

1.75 ± 0.02mm

Diameter consistency

Surface

Method of measurement

standard

characteristic

Visual plus touch

Smooth, rounded, uniform thickness

surface

Visual plus touch

No bubbles, bulges, spots, etc

details

Visual additive color charts

The color is uniform with the swatch

pigment

visual

Neat and unblocked

rolling

Physical property

Method of measurement

standard

characteristic

density

1.08(g/cm³)

standard

distortion temperature

92℃

standard

melt index

8g/10min

standard

Vika softening temperature

96℃

standard

Mechanical behavior

Method of measurement

standard

characteristic

tensile strength

35 MPa

standard

elongation at break

50%

standard

bending strength

55 MPa

standard

flexural modulus

1800 MPa

standard

Cantilever beam notch impact

60J/M

standard

×
